Before jumping in to install and run IPFS Cluster, it is important to clarify some basic concepts.

IPFS Cluster Architecture

The IPFS Cluster software consists of two binary files:

  • ipfs-cluster-service runs a Cluster peer (similar to ipfs daemon) using a configuration file and by storing some information on disk.
  • ipfs-cluster-ctl is used to communicate with a Cluster peer and perform actions such as pinning IPFS CIDs to the Cluster.

The Cluster peer communicates with the IPFS daemon using the HTTP API (localhost:5001). Therefore, the IPFS daemon must be launched and running separately.

Usually, ipfs-cluster-ctl is used on the same machine or server on which ipfs-cluster-service is running. For example, ipfs-cluster-ctl pin add <hash> will instruct the local Cluster peer to submit a pin to the Cluster.  The different peers in the Cluster will then proceed to ask their local  IPFS daemons to pin that content. The number of pins across the Cluster  will depend on the replication factor set in the Cluster configuration  file.

The Cluster swarm

IPFS Cluster is a fully distributed application. ipfs-cluster-service runs a Cluster peer and all peers are equal. Cluster peers form an separate, isolated libp2p [private] network, which uses the cluster_secret (a 32-bit hex-encoded passphrase present in the configuration of every peer).

This network does not interact with the main IPFS network, nor with  other private IPFS networks and is solely used so that Cluster peers can  communicate and operate. The network uses a number of blocks also used  by IPFS (DHT, PubSub, Bitswap…) but, unlike IPFS, does not enjoy public  bootstrappers.

This means that Cluster peers will normally need their own  bootstrappers (it can be any peer in the Cluster), although sometimes  they can rely on mDNS discovery.

This also means that Cluster peers operate separately from IPFS with regards to NAT hole punching, ports etc.

The shared state: consensus

All peers in the Cluster maintain a global pinset. Making every peer  maintain the same view of the pinset regardless of concurrent pinning  operations and on a distributed application layout requires coordination  given by what is called a consensus component. Cluster supports two implementations:

  • A CRDT-based approach, based on Conflict-Free Replicated Datatypes
  • A Raft-based approach, based on a popular log-based consensus algorithm

The relevant details and trade-offs between them are outlined in the Consensus Components section. The choice (which must be performed during initialization and  cannot be easily changed), heavily affects the procedures for adding,  removing and handling failures in Cluster peers.

The shared state can be inspected with ipfs-cluster-ctl pin ls and is the only piece of information present locally in every peer. Pin status (status) information, or peers information (peers ls)  for other than the peer that is running the command, must be obtained  at runtime from their respective peers and assembled together.
