IPFS Proxy

Ipfs Dec 15, 2019

The IPFS Proxy is an endpoint which presents the IPFS HTTP API in the following way:

  • Some requests are intercepted and trigger cluster operations
  • All non-intercepted requests are forwarded to the IPFS daemon attached to the cluster peer

This endpoint is enabled by default, and listens by default on /ip4/ and is provided by the ipfshttp connector component. It can be disabled by removing its section from the service.json configuration file.

The requests that are intercepted are the following:

  • /add: the proxy adds the content to the local ipfs daemon and pins the resulting hash[es] in cluster.
  • /pin/add: the proxy pins the given CID in cluster.
  • /pin/update: the proxy updates the given pin to a new one in cluster.
  • /pin/rm: the proxy unpins the given CID from cluster.
  • /pin/ls: the proxy lists the pinned items in cluster.
  • /repo/stat: the proxy responds with aggregated /repo/stat from all connected IPFS daemons.

Responses from the proxy mimic the IPFS daemon responses, thus  allowing to drop-in this endpoint in places where the IPFS API was used  before. For example, you can use the go-ipfs CLI as follows:

  • ipfs --api /ip4/ pin add <cid>
  • ipfs --api /ip4/ add myfile.txt
  • ipfs --api /ip4/ pin rm <cid>
  • ipfs --api /ip4/ pin ls The IPFS Proxy endpoint can be used with the IPFS companion extension.

The responses would come from cluster, not from go-ipfs.  The intercepted endpoints aim to mimic the format, headers and response  codes from IPFS. If you have custom headers configured in IPFS, you  will need to add their names them to the ipfsproxy.extract_headers_extra configuration option.
